Revolutionizing the handling of frozen samples stored in 2D-coded tubes, RITrack utilizes innovative radio-frequency tagging to eliminate the challenges posed when no line of sight is clear for 2D coded tubes, such as ice formation on tube and rack bases. With the ability to store identities for up to 96 tubes in a rack, it works seamlessly with cryotubes straight from the freezer, including vapor-phase LN2 storage, safeguarding thermally sensitive samples without requiring warming or thawing. Compatible with standard SBS racks, RITrack lowers operational costs, offering a cost-effective and durable sample tracking solution that enhances lab productivity.
As RITrack tags use standard RFID technology, they can also be read by any smartphone device with Near Field Communication (NFC). An easy-to-use app can be downloaded free from the App Store or Google Play to any compatible smartphone. The app allows the tag information to be read and the data displayed in either graphical or tabular format. This makes it easy to identify any individual tube in the frozen rack together with its location. Simply open the freezer, withdraw a rack and offer it up to the phone to see all the available tubes in that rack, eliminating the inefficiency of taking one or more cold racks back to the lab.
Using the Pick List function of the app, tubes from several different racks can be checked-off right in front of the freezer, again saving valuable technician time.
RITrack data for every individual tube as well as the rack barcode can be read or stored to the tag in a matter of seconds. This makes it very quick and easy to manage frozen samples without thawing or removing ice, thus saving valuable time and protecting delicate thermally sensitive materials in the stored tubes.
Key Features
Revolutionizing Sample Tracking in Cryogenic Storage
- Use RITrack Mirage to decode tubes, then write/re-write data onto tag
- Tags store individual tube identities, up to 16 characters, for up to 96 tubes in a rack, their positions and rack ID
- Tags fit most commercially available SBS racks to lower operational costs
- Compatible with racks covered in ice and with racks stored in vapor-phase LN2, no warming or thawing therefore protecting thermally sensitive samples
- RITrack Mirage can read stored data back from the tag and compare with photographic data to identify if any tubes have been moved, removed or replaced
- DP5 RITrack software will highlight tube in rack changes in the visual interface as well as in the tabulated data
- RFID tags last and function for the whole life of the racks, with unlimited re-writes
- Unique RFID technology exclusive to Azenta Life Sciences
Flexible Reading with Smartphone App
- Intuitive, free smartphone application (Google Play/ Apple App Store)
- Simply open the freezer, withdraw a rack and offer it up to the phone to see all the available tubes in that rack
- Data displayed in either graphical or tabular format
- Pick list function allows for checked-off right in front of the freezer, saving valuable technician time
- Protect thermally sensitive samples by reading directly at freezer
Cryoprotection™
- The occurrence of condensation whilst scanning 2D datamatrix tubes straight from cryogenic storage is well known
- Ziath’s Cryoprotection is a special proprietary coating that eliminates the condensation and ensures uninterrupted scanning
- Ziath’s method for eliminating condensation uses no extra electrical components
- Prevents the scanner window from misting up when a cold rack is scanned
- Our passive technology does not use heat or blown air
- No risk of accidentally thawing your samples
- Increased reliability and insurance that the cost of this option is at acceptable levels
